ATVEI.L30 - License GS3 BSL AUTOVEI

Product Information

SKU:

ATVEI.L30

License GS3 - allows to read & write FLASH & EEPROM of GS3 gearbox ECU.

ZF-Astronic.

GS3.0  20 Pin (truck)  since 2000: MAN, DAF, IVECO, RENAULT

GS3.3  20 Pin (truck)  since 2005: MAN, DAF, IVECO

GS3.6  20 Pin (truck)  since 2010: DAF

Operation modes:

• BSL
• DC

In BSL mode:

• Read / Write full Flash and Eeprom
• Need to open ECU and solder adapter
• No checksum

In DC mode:

• Only diagnostics
• No need to open ECU

GS3.0 with two external flash:

• BSL GS3.0 C167CS A:
• FLASH: Am29F400B, 512 KB
• EEPROM: 28HC64B, 2 KB
• BSL GS3.0 C167CS B:
• FLASH: Am29F200B, 256 KB
• EEPROM: 24C16B, 2 KB

GS3.3 with two MCU:

• BSL GS3.3 ST10F276 A:
• PFLASH: 10F276, 512KB
• DFLASH: 10F276, 320 KB
• EEPROM: 25LC640, 8KB
• BSL GS3.3 ST10F276 B:
• PFLASH: 10F276, 512KB
• DFLASH: 10F276, 320KB

GS3.6 with two MCU:

• BSL GS3.6 ST10F276 A:
• PFLASH: 10F276, 512KB
• DFLASH: 10F276, 320 KB
• EEPROM: 25LC640, 8KB
• BSL GS3.6 ST10F276 B:
• PFLASH: 10F276, 512KB
• DFLASH: 10F276, 320KB

Hardware requirements:

• VEI V6/V7 device
• Direct Connect 2U tool with OBD2 power cable
• DC2U-GS3 cable
• DC2U-ISP7 cable
