FN00F - Full ABRITES Software Package for FCA vehicles (FIAT, Lancia, Alfa Romeo)

Product Information

SKU:

FN00F

This package contains all the ABRITES special functions for FCA vehicles: FN015, FN021, FN022, FN023 and FN024.

The FN015 is dedicated to reading and updating ECU’s internal configuration memory for Fiat/Lancia/Alfa/FCA (FIAT/CHRYSLER AUTOMOBILES) vehicles by OBD.

It has the following functionalities:

• Read/update ConfData by OBD
• Calibration by OBD
• Make VIRGIN by OBD
• (When not possible to work by OBD, boot mode is required)

Supported Units:

• BOSCH: EDC15C5 EURO2, EDC15C7 EURO3, ME7.3H4 (BOOT MODE), ME7.3.1 (BOOT MODE)
• MARELLI: IAW 4AF, IAW 4EF, IAW 59F, IAW 59M, IAW 5AF (HW30x, ST10F168), IAW 5AF (HW60x, ST10F269), IAW 5AM, IAW 5NF, IAW 5SF3/5SF8 (Kline), IAW 5SF3 (CAN), IAW 5SF8 (CAN), IAW 5SF9 (CAN), 8GMF, 8GMK, 8GSF, 8GSW/&GMW, 9GF, MJD 6JF (Kline), MJD 6F3 (Kline), MJD 6F3 (CAN), MJD 8F2 (Kline), MJD 8F2 (CAN), MJD 8F3 (CAN), MJD 9DF

Some of the Supported Models:

• ALFA: 145 - 1.9 JTD, 146 - 1.9 JTD, 147 - 1.9 JTD 16V; 1.9 JTD 8V, 156 - 1.9 JTD; 2.4 JTD, 166 - 2.4 JTD and others.
• FIAT: Bravo - 1.9 JTD, Brava - 1.9 JTD, Doblo - 1.9 JTD, Ducato - 2.0 JTD; 2.3 JTD; 3.8 JTD, Marea - 1.9 JTD; 2.4 JTD, Marengo - 1.9 JTD, Fiat Punto - 1.9 JTD, Palio - 1.9 JTD, Stilo - 1.9 JTD, Siena - 1.9 JTD, Scudo - 2.0 JTD and others.
• FIAT: New Panda, Idea, Doblo, Punto, Grande Punto, Cinquecento (with 1.3 IAW MultiJet MJD 6JF)
• LANCIA: K - 1.9 JTD, Lybra - 1.9 JTD, 2.4 JTD, Thesis - 2.4 JTD, Z - 1.9 JTD and others; Musa, Ypsilon (with 1.3 IAW MultiJet MJD 6JF)

The FN021 allows proxi alignment between the BCM and the other modules in the vehicle. In case of a BCM replacement, lets you get the current car configuration from the IPC. FCA

Proxi alignment tool is an outstanding solution allowing:

• Adding/removing modules from the CAN Configuration
• Car configuration - customisation options (enabling and disabling features like start/stop system, rain sensors, gearshift sensors, indicators, etc.)
• Different retrofitting options
• Read/Update and save Proxi alignment data to a file

Supported models:

• ALFA: Giulietta (940), Giulia (952), Stelvio (949)
• FIAT: 500 (312), 500e (332) (New FIAT 500), 500L (330), 500X (334), Doblo (263), Ducato (250), Fiorino (225), Tipo (356), Viaggio (343)
• JEEP: Renegade (520)
• RAM: ProMaster City (636)

For models, not mentioned in the list above, there is the "Other Models" option which will do the Proxi alignment in the car, but won't let you personalize the settings

The FN022is a powerful license dedicated to the PIN code reading and key and remote-control programming of Fiat/Lancia/Alfa/FCA (FIAT CHRYSLER AUTOMOBILES) vehicles for mechanical keys and keyless access keys.

License highlights:

• Program keyless keys for the latest FCA vehicles, manufactured after 2020.
• New models 2020+ added for key programming!
• Alfa Romeo Guilia and Stelvio
• Jeep Renegade, Compass, Wrangler, Gladiator
• Fiat 500X
• Dodge RAM (DT)
• Fiat Qubo 2020+ and Fiorino 2020+
• Maserati Levante and Ghibli

Main functionalities:

• PIN reading and Key programming
• Transponders/Keys preparation
• Remote control programming
• BCM - Configuration data read and update PIN
• Key learning and remote programming by OBDII
