VN00KM - Full ABRITES Mileage Calibration Software Package for VAG vehicles

Product Information

SKU:

VN00KM

Full set of mileage recalibration special functions for VAG including the VN007, VN021, VN022, VN023.

The VN007 is one of very few solutions for mileage recalibration of the MQB platform-based vehicles, equipped with VDO/Continental dashboard*.

Supported Models:

• AUDI: A3/S3 (8V) 2012+, Q2; А4/А5/Q5 (up to 2014);
• SEAT: Leon (5F) 2012+, Ibiza, Ateca, Toledo 2012+;
• SKODA: Fabia, Octavia III 2012+, RAPID 2012+, Kodiaq, Superb III;
• VOLKSWAGEN: Golf 7, Polo, Tiguan II, Touran II 2012+, Passat B8

*Note: JCI and Virtual Cockpit dashboards are supported with this license when using the ABRITES RH850/V850 Programmer.

An AVDI interface with an active AMS is required in order to use this special function.

The VN021 license allows extracting the Immobilizer data from dump of RH850 processors, used in VAG MQB dashboards with Megamos-AES keys.

Upon reading the RH850 processor using the ABRITES Programmer, CS, MAC, Keys, and PowerClass information is visualised in the software.

Using the VN021 you can write Immo Data and the mileage onto VAG MQB dashboards with RH850 processors. This means unlimited reading and writing abilities for all types of RH850 processors in VAG MQB dashboards using the ABRITES RH850/V850 Programmer. It is also valid for V850 processors.

This data can then be used for adding a spare key to the vehicle. It can also be used to exchange the instrument cluster, which requires extracting Immo data from both the replacement module, and the donor one.

This functionality is ideal for dashboard exchange and retrofitting purposes! The VN021 allows you to exchange analogue for digital dashboards in vehicles equipped with dashboards using RH850 and V850 processors.

Functionalities:

• Reading Immo data from dump of RH850/V850 processors in VAG MQB dashboards
• Writing Immo data on RH850/V850 processors in VAG MQB dashboards
• Mileage recalibration, including RH850 dashboards (for replacement purposes)
• Spare key addition
• Instrument cluster exchange
• Retrofit

Supported vehicles:

• VAG vehicles with the following dashboards
• VDO MQB Analogue RH850
• VDO MQB Virtual Cockpit RH850
• VDO MQB Analogue V850
• VDO MQB Virtual Cockpit V850
• JCI MQB Analogue V850

The VN022 license is developed to work with the ABRITES RH850/V850 Programmer for writing mileage data in non-ImmoV dashboard odometers.

This functionality is suitable for VW Golf 8 generation vehicles, allowing the odometer calibration in Volkswagen, Audi, Seat, Skoda and other VAG vehicles on the same platform.

Functionalities:

• RH850 processor odometer writing in Continental/VDO dashboards (not related to the Immobilizer)

Supported vehicles:

• VW Golf 8
• other vehicles from the VAG group from the same generation

(where the immobilizer is not integrated in the dashboard)

The VN023 license is another lincense intended for working with the ABRITES RH850/V850 Programmer which allows changes the mileage in Visteon and JCI dashboads,

equipped with RH850 processors. This functionality is suitable for VAG MQB vehicles (Volkswagen, Audi, Seat, Skoda and other VAG vehicles on the same platform).

Functionalities:

• RH850 processor odometer writing in Visteon/JCI dashboards

Supported vehicles:

• All VW/Seat/Skoda/Audi models with Visteon/JCI dashboard with RH850
