Product Information
SKU:
MN032
MN032 is a powerful software license by ABRITES, allowing you to work with used or new FBS4 modules in Mercedes-Benz vehicles effortlessly.
Functionalities:
- Set FBS4 Electronic Control Modules to virgin state
- Read the personalization data from a FBS4 Control Modules and save it to a file
- Program personalization data from a previously saved FBS4 file
- Program personalization data from a previously read dump file (dflash/ EEPROM)
- VIN programming
- Read and display FBS4 status by OBD for ALL FBS4 Control Modules
- FBS4 Control Modules Activation
Supported modules:
VGS-FDCT/VGS2-FDCT, VGS4-NAG2 (MN035 required!), VGSNAG3, 8G FDCT, GT-DCT
- Reading FBS4 data via OBD
- Setting to virgin state and personalization via ZN151
VGS-FDCT/VGS2-FDCT, VGSNAG3
- Setting to virgin state and personalization via ABPROG (or SET088) VGS4-NAG2 (0 and 500)
DSM (all types of models) installed in VGS4-NAG2 (7G) cars
- Reading and writing FBS4 data via internal CAN-Bus connection
- Setting to virgin state via internal CAN-Bus connection – No need to open the module!
- Personalization via internal CAN-Bus connection – No need to open the module!
For ALL Engine modules
- Reading FBS4 data by OBD
- Setting to virgin state by OBD MED17, EDC17, SID310, CRD3 ECUs (CR40, CR41, CR42, CR43, CR6, CR60, CR61, MED40, MED177, MED1773, MED1775, CRR1, CRR1+, CRD3, CRD3S2)
- Setting to virgin state via ABRITES Distribution Box Set (ZN151) - required for MED41, MRD1, MRG1, CRR2 up to 2021
- Personalization by OBD (Extended personalization)
Hybrid vehicle ECUs (INV20EM01 and derivatives)
- Reading FBS4 data by OBD
- Setting to virgin state via OBD – No need to open the module!
- Personalization by OBD (Extended personalization)
Electric vehicle ECUs (EM01, EM02)
- Reading FBS4 data by OBD
- Personalization by OBD (Extended personalization)
Required tools:
- AVDI – essential in order to use all ABRITES-based products and establish OBD connection
- Abrites Distribution Box Set (ZN151)
- Abrites ABPROG (ZN030)
- DSM/ISM Direct CAN BUS Connection Cable (CB034)
- Mercedes-Benz MD1/MG1 ECU connection cable for FBS4 Manager and ECU Programming Tool (CB030)
- Extended Cable Set for all TCUs which require bench connection (CB403) – for owners of the ZN051 (older iteration of the Distribution Box Set)
